Transfer or Import and Export  Waypoints from SD Card to Raymarine C95 – C97 – C125 – C127 – E7 – E7D – E95 – E97 – E125 – E127 Raymarine GPS or MFD (Multi Function Display)

Note: For all late model Raymarine GPS, you must have the Raymarine waypoint format (.fsh) as your file name to be transferred or imported to your Raymarine GPS.

To retrieve your waypoints, routes, and tracks from the Micro SD card, perform the following.

  1. Power up your Raymarine GPS Model c95/c97/c125/c127/e7/e7D/e95/e97/e125/e127 MFD and allow it to boot up.
  1. Press the OK button to acknowledge the Limitations of Use.
  1. Insert the the Micro SD memory card containing our Raymarine waypoint file provided in the Raymarine GPS File folder of your email into either of the c95/c97/c125/c127/e7/e7D/e95/e97/e125/e127 Raymarine GPS memory card slots, noting whether you have inserted the memory card into the upper or lower memory card reader slot.
  1. Press the Home Screen’s MY DATA feature.
  1. Select RETRIEVE FROM CARD from the My Data command list.
  1. When the Select External Storage dialog is displayed, press SD1 if you have inserted the Micro SD memory card into the upper memory card reader slot otherwise press SD2
  1. To retrieve all waypoint data, press the RETRIEVE WAYPOINTS FROM CARD on the Retrieve from Card command list.
  1. Press the RETRIEVE ALL feature to retrieve all waypoints.
  1. Press the OK button on the Card in Use dialog.
  2. Press the BACK button twice
  3. Press the Home Screen’s MY DATA feature.
  4. Press the EJECT CARD on the My Data command list.
  5. When the Eject External Storage dialog is displayed, press SD1 if you had inserted the microSD memory card into the upper memory card reader slot otherwise press SD2 .
  6. Remove the microSD memory card form the memory card reader.
  7. Press the OK button. You’re done.



Info provided by GPS Fishing Maps, LLC
